| AMBIENT | 40 deg C |
| APPLICATION | Turbine, mix flow and propeller pumps |
| BEARING | Ball |
| CAPACITOR TYPE | Start Capacitor |
| CATALOG NUM | HT7P2BLE |
| COUNTRY OF ORIGIN | MEX |
| EFFCIENCY | Premium |
| ENCLOSURE | Tefc |
| FEATURES | Class F Insulation/1.15 Service Factor/Maximum 40 deg C Ambient, 3,300 Feet Altitude/Capacitor Start Design/Corrosion Resistant Mill & Chemical Duty Paint/NRR = Non-Reverse Ratchet/Discount Symbol: DS-7VS |
| FRAME | 213T |
| HORSE POWER | 7-1/2 HP |
| INSULATION CLASS | F |
| LEAD TIME | 1 |
| LENGTH | 21.5 IN |
| MANUFACTURER | Nidec Motor Corporation |
| MATERIAL | Aluminum |
| MFG MODEL NUM | HT7P2BLE |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR ORIENTATION | Vertical Shaft Down |
| MOTOR TYPE | 3PHASE |
| MOUNTING | P-Base |
| NEMA | B |
| NOMINAL EFFICIENCY | 91.70% |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ODE BEARING SIZE | 6208-2Z-J/C3 |
| OUTER DIAMETER | 10 IN |
| OVERLOAD | None |
| PACKAGE WEIGHT | 210 lb |
| PRODUCT GROUP | 3050 |
| PRODUCT TYPE | AC Motor |
| RPM | 1800(1) |
| SERVICE FACTOR | 1.15 |
| SKU | NM-HT7P2BLE |
| STARTING TYPE | Direct On Line |
| TYPE OF OVERLOAD PROTECTOR | No Protection |
| UOM | Each |
| UPC NUMBER | 786382113322 |
| VOLTAGE | 230/460 V |
