| AMBIENT | 40°C |
| BEARING | Unit |
| BRAND | FASCO |
| CATALOG NUM | UB560 |
| CE | No |
| COUNTRY OF ORIGIN | China |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 0.18 A |
| FRAME | UNIT BEARING |
| FRAME LENGTH | 3.12 IN |
| FRAME MATERIAL | Aluminum |
| FREQUENCY | 60 HZ |
| HEIGHT | 3.75 IN |
| HORSE POWER | 6 W |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 4.25 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | UB560 |
| MIN QUANTITY INCREMENT | 2 |
| MOTOR TYPE | Shp |
| MOUNTING | 2 BOSS/OSE 5 HOLES |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Impedance |
| PART ID | UB560 |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise Opposite Shaft End |
| RPM | 1550(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 1/4 X 20 IN X 0.415 IN |
| SHAFT DIAMETER IN IN | 1/4 X 20 IN |
| SHAFT EXTENSION | 0.415 IN |
| SHAFT TYPE | Threaded |
| SKU | WUB-560 |
| SPEED | 1550 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674069917 |
| VOLTAGE | 230 V |
| WEIGHT STATIC | 1 LB |
| WIDTH | 4.25 IN |
