| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | FASCO |
| C DIMENSION | 3.59 IN |
| CATALOG NUM | K146 |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Air Over |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 2.1 A |
| FRAME | C-FRAME |
| FREQUENCY | 60 HZ |
| HEIGHT | 3.63 IN |
| HORSE POWER | 1/20 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 11.5 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | K146 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | Extended Studs |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Automatic |
| PART ID | K146 |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise |
| RPM | 3000(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.250 IN X 1 IN |
| SHAFT DIAMETER IN IN | 0.250 IN |
| SHAFT EXTENSION | 1 IN |
| SHAFT TYPE | Round |
| SKU | WK-146 |
| SPEED | 3000 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 818508021645 |
| VOLTAGE | 120 V |
| WEIGHT STATIC | 2.63 LB |
| WIDTH | 9.25 IN |
