| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | FASCO |
| C DIMENSION | 4.10 IN |
| CATALOG NUM | K109 |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | No |
| DUTY | Air Over |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 0.77 A |
| FRAME | C-FRAME |
| FREQUENCY | 60 HZ |
| HEIGHT | 3.63 IN |
| HORSE POWER | 1/75 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 11.5 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | K109 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | Extended Studs |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Automatic |
| PART ID | K109 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Shaft End |
| RPM | 3000(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.218 IN X 2.37 IN |
| SHAFT DIAMETER IN IN | 0.218 IN |
| SHAFT EXTENSION | 2.37 IN |
| SHAFT TYPE | Flat |
| SKU | WK-109 |
| SPEED | 3000 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Fasco Industries Inc |
| THRU BOLTS EXTENSION | Yes |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 818508021515 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 1.50 LB |
| WIDTH | 9.25 IN |
