| BEARING | Ball |
| BRAND | FASCO |
| C DIMENSION | 6.86 IN |
| CATALOG NUMBER | 9721 |
| CONNECTION DRAWING NO | 61305863 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 0.9/0.43/1.1/0.49 A |
| FRAME | 3.3 |
| FREQUENCY | 50/60 HZ |
| HEIGHT | 5.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 8.81 IN |
| MANUFACTURE MODEL NUMBER | 9721 |
| MANUFACTURER | Fasco Industries Inc |
| MOTOR TYPE | Psc |
| MOUNTING | Extended Studs |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 1/12 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/12,1800,115/208-230,3.3,OAO,PSC |
| PRODUCT SKU | WF-9721 |
| ROTATION | Reversible |
| RPM | 1350/1550(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.312 IN X 3.25 IN |
| SHAFT DIAMETER (IN IN.) | 0.312 IN |
| SHAFT EXTENSION | 3.25 IN |
| SHAFT TYPE | Flat |
| SPEED | 1350/1550 |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115/208-230 V |
| WIDTH | 5.88 IN |
