| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | ELCO |
| C DIMENSION | 4.20 IN |
| CATALOG NUM | EC34W115 |
| CE | Yes |
| CSA | Yes |
| DUTY | Continuous Air Over |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 1.6 A |
| FRAME | UNIT BEARING |
| FRAME LENGTH | 3.58 IN |
| FRAME MATERIAL | Aluminum |
| FREQUENCY | 60 HZ |
| HEIGHT | 5 IN |
| HORSE POWER | 34 W |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 5 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | EC34W115 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | 1 BOSS/PE AND OPE 3 HOLES |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| ORIENTATION | Any |
| OVERLOAD | Thermostat |
| PART ID | EC34W115 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Shaft End |
| RPM | 1550 |
| SHAFT | 0.275 IN X 0.61 IN |
| SHAFT DIAMETER IN IN | 0.275 IN |
| SHAFT EXTENSION | 0.61 IN |
| SHAFT TYPE | Flat |
| SKU | WEC-34W115 |
| SPEED | 1550 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 818508023793 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 5.50 LB |
| WIDTH | 5.31 IN |
