| BEARING | Sleeve |
| BRAND | ELCO |
| C DIMENSION | 3.60 IN |
| CATALOG NUMBER | EC16W115 |
| CONNECTION DRAWING NO | LSM 5 |
| DUTY | Continuous Air Over |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 0.89 A |
| FRAME | UNIT BEARING |
| FREQUENCY | 60 HZ |
| HEIGHT | 5 IN |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 5 IN |
| MANUFACTURE MODEL NUMBER | EC16W115 |
| MANUFACTURER | Fasco Industries Inc |
| MOTOR TYPE | Shp |
| MOUNTING | 1 BOSS/PE AND OPE 3 HOLES |
| NUMBER OF POLES | 4 |
| ORIENTATION | Any |
| OUTPUT | 16 W |
| OVERLOAD | Thermostat |
| PRODUCT NAME | 16W,1800.115,3.3" ,TEAO,SHP,CCWDE,ELCO NU |
| PRODUCT SKU | WEC-16W115 |
| ROTATION | Counterclockwise Shaft End |
| RPM | 1550 |
| SHAFT | 0.275 IN X 0.63 IN |
| SHAFT DIAMETER (IN IN.) | 0.275 IN |
| SHAFT EXTENSION | 0.63 IN |
| SHAFT TYPE | Flat |
| SPEED | 1550 |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 5.31 IN |
