| AMBIENT | 40 °C |
| BEARING | Sleeve |
| BRAND | FASCO |
| CATALOG NUM | D974 |
| CE | No |
| CONNECTION DRAWING NO | NP24X327722 |
| CSA | Yes |
| DUTY | Continuous Air Over |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 2.30-1.60-1.20 A |
| FRAME | 48 |
| FRAME LENGTH | 4.57 |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.02 IN |
| HORSE POWER | 1/2-1/3-1/4 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 14.24 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | D974 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Rings |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 8 |
| NUMBER OF SPEEDS | 3 |
| PART ID | D974 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise |
| RPM | 825(3) |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER IN IN | 0.5 |
| SHAFT EXTENSION | 4.5 |
| SHAFT TYPE | Flat |
| SKU | WD-974 |
| SPEED | 825 |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 818508020853 |
| VOLTAGE | 277 V |
| WEIGHT STATIC | 12.14 LB |
| WIDTH | 6.04 IN |
