| AMBIENT | 40�C |
| BEARING | Sleeve |
| BRAND | Fasco |
| C DIMENSION | 8.37 IN |
| CATALOG NUM | D9623 |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | No |
| CURRENT2 | 1 A |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FRAME | 3.3 |
| FRAME LENGTH | 3.2 IN |
| FRAME MATERIAL | Steel |
| FRAME SUFFIX | None |
| FREQUENCY | 60 HZ |
| HEIGHT | 4.25 IN |
| HORSE POWER | 1/40 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 9.50 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | D9623 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | SHADED POLE |
| MOUNTING | Extended Studs |
| NUMBER OF PHASES | 1 PH |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Thermally Protected |
| POWER RATING IN KW | 0.02 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Shaft End |
| RPM | 1500(1) |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER IN IN | 0.313 |
| SHAFT EXTENSION | 2.5 |
| SHAFT TYPE | Flat |
| SKU | WD-9623 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Regal Rexnord |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 818508020846 |
| VOLTAGE | 115 V |
| WEIGHT | 3.50 LB |
| WIDTH | 4.25 IN |
