| ACTIVE ONLINE | 1 |
| AMBIENT | 40�C |
| BEARING | Sleeve |
| BRAND | Fasco |
| C DIMENSION | 6.98 IN |
| CART2QUOTE QUOTABLE | Use Default |
| CATALOG NUM | D9487 |
| CATALOG NUM STATIC | D9487 |
| CATEGORIES | Motors & Drives,Blowers,OEM Replacement |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | No |
| CURRENT | 1.3 A |
| CURRENT2 | 1.20-1.30 A |
| DESCRIPTION | 1/12,1800,230,3.3, OAO,OEM |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FRAME | 3.3 |
| FRAME LENGTH | 4.58 IN |
| FRAME MATERIAL | Steel |
| FRAME STATIC | 3.3 |
| FRAME SUFFIX | None |
| FREQUENCY | 60 HZ |
| GIFT WRAPPING AVAILABLE | No |
| HEIGHT | 4.50 IN |
| HORSE POWER | 1/12 HP |
| HORSE POWER STATIC | 1/12 |
| INSULATION CLASS | B |
| IS FEATURED | No |
| LEAD TIME | 21 |
| LENGTH | 8.00 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | D9487 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | SHADED POLE |
| MOUNTING | Bracket |
| NUMBER OF PHASES | 1 PH |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Thermally Protected |
| POWER RATING IN KW | 0.06 |
| ROTATION | Counterclockwise Shaft End |
| RPM | 1500(1) |
| RPM STATIC | 1800 |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER IN IN | 0.313 |
| SHAFT EXTENSION | 2.15 |
| SHAFT TYPE | Flat |
| SHORT DESCRIPTION | 1/12,1800,230,3.3, OAO,OEM |
| SKU | WD-9487 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Regal Rexnord |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 818508020778 |
| VOLTAGE | 230 V |
| VOLTAGE STATIC | 230 |
| WEIGHT | 4.97 LB |
| WIDTH | 4.50 IN |
