| AMBIENT | 60 °C |
| BEARING | Ball |
| BRAND | FASCO |
| CATALOG NUM | D2852 |
| CE | No |
| CONNECTION DRAWING NO | NP24X350100 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 1.90 A |
| FRAME | 48 |
| FRAME LENGTH | 6.07 |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.5 IN |
| HORSE POWER | 1-3/4 HP |
| LEAD TIME | 21 |
| LENGTH | 14.12 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | D2852 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Lug |
| NUMBER OF PHASES | 1 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Automatic |
| PART ID | D2852 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER IN IN | 0.62 |
| SHAFT EXTENSION | 3.25 |
| SHAFT TYPE | Keyed |
| SKU | WD-2852 |
| SPEED | 1075 |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 818508022413 |
| VOLTAGE | 208-230/460 V |
| WEIGHT STATIC | 24 LB |
| WIDTH | 6.38 IN |
