| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Fasco |
| CATALOG NUM | D277A |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 0.65,0.4,0.3 A |
| FRAME | 42 |
| FRAME LENGTH | 4.33 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.44 IN |
| HORSE POWER | 1/10,1/12,1/20 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 22.88 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | D277A |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | PSC |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| OVERLOAD | Automatic |
| PART ID | D277A |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise Lead End |
| RPM | 1050(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 8.25 X .5 X 8.25 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 8.25 X .5 X 8.25 IN |
| SHAFT TYPE | Flat |
| SKU | WD-277A |
| SPEED | 1050 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 818508029153 |
| VOLTAGE | 277 V |
| WEIGHT STATIC | 11.53 LB |
| WIDTH | 6.25 IN |
