| AMBIENT | 40 °C |
| BEARING | Sleeve |
| BRAND | FASCO |
| CATALOG NUM | D247 |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 1.0/0.7/0.5 A |
| FRAME | 42 |
| FREQUENCY | 60 HZ |
| HEIGHT | 25 IN |
| HORSE POWER | 1/6-1/8-1/12 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 6.63 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | D247 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Rings |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 3 |
| PART ID | D247 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise |
| RPM | 1550(3) |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER IN IN | 0.5 |
| SHAFT EXTENSION | 8 |
| SHAFT TYPE | Flat |
| SKU | WD-247 |
| SPEED | 1550 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 815585029243 |
| VOLTAGE | 230 V |
| WEIGHT STATIC | 11.80 LB |
| WIDTH | 5.13 IN |
