| BEARING | Ball |
| BRAND | FASCO |
| CATALOG NUMBER | D227 |
| DUTY | Continuous Air Over |
| ENCLOSURE | TOTALLY ENCLOSED FAN COOLED |
| FL AMPS | 1.80 A |
| FRAME | 3.3 |
| FREQUENCY | 60 HZ |
| HEIGHT | 4.5 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 8 IN |
| MANUFACTURE MODEL NUMBER | D227 |
| MANUFACTURER | Fasco Industries Inc |
| MOTOR TYPE | Shp |
| MOUNTING | Extended Studs |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 1/20 HP |
| PRODUCT NAME | 1/20,1800,115,3.3,TEAO,SHP |
| PRODUCT SKU | WD-227 |
| ROTATION | Counterclockwise |
| RPM | 1500(1) |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER (IN IN.) | 0.312 |
| SHAFT EXTENSION | 2.3 |
| SHAFT TYPE | Flat |
| SPEED | 1500 |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 4.5 IN |
