| AMBIENT | 40 °C |
| BEARING | Sleeve |
| BRAND | FASCO |
| CATALOG NUM | D1196 |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous Air Over |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 1.5 A |
| FRAME | 3.3 |
| FRAME LENGTH | 2.96 |
| FRAME MATERIAL | Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 9 IN |
| HORSE POWER | 1/30 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 6.5 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | D1196 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | Lug |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 1 |
| NUMBER OF SPEEDS | 1 |
| PART ID | D1196 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise |
| RPM | 3200(1) |
| SHAFT DIAMETER IN IN | 0.313 |
| SHAFT EXTENSION | 2.31 |
| SHAFT TYPE | Flat |
| SKU | WD-1196 |
| SPEED | 3200 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 815585028246 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 3.40 LB |
| WIDTH | 5.13 IN |
