| BEARING | Sleeve |
| BRAND | FASCO |
| CATALOG NUMBER | D1180 |
| DUTY | Continuous Air Over |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 1.5 A |
| FRAME | 3.3 |
| FREQUENCY | 60 HZ |
| HEIGHT | 7 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 6.25 IN |
| MANUFACTURE MODEL NUMBER | D1180 |
| MANUFACTURER | Fasco Industries Inc |
| MOTOR TYPE | Shp |
| MOUNTING | Lug |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 1/20 HP |
| PRODUCT NAME | 1/20,3600,115,3.3,OPEN,SHP |
| PRODUCT SKU | WD-1180 |
| ROTATION | Clockwise |
| RPM | 3300(1) |
| SHAFT DIAMETER (IN IN.) | 0.313 |
| SHAFT EXTENSION | 2.1 |
| SHAFT TYPE | Flat |
| SPEED | 3300 |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 6.06 IN |
