| AMBIENT | 40 °C |
| BEARING | Sleeve |
| BRAND | FASCO |
| CATALOG NUM | D1090 |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 0.80 A |
| FRAME | 42 |
| FRAME LENGTH | 3.13 |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 27.5 IN |
| HORSE POWER | 1/15 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 6.5 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | D1090 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Extended Studs |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 2 |
| PART ID | D1090 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise |
| RPM | 1100(2) |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER IN IN | 0.5 |
| SHAFT EXTENSION | 10.5 |
| SHAFT TYPE | Flat |
| SKU | WD-1090 |
| SPEED | 1100 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Automatic |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 815585028079 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 11 LB |
| WIDTH | 6.25 IN |
