| AMBIENT | 40°C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 16.8 IN |
| CATALOG NUM | CS89 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 1.6 A |
| FRAME | 42 |
| FRAME LENGTH | 3.8 IN |
| FRAME MATERIAL | Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| HORSE POWER | 1/10 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 25.4 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | CS89 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| OVERLOAD | Automatic |
| PART ID | CS89 |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise Lead End |
| RPM | 1100,900,700(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 9.3 X 0.50 X 9.3 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 9.3X0.50X9.3 IN |
| SHAFT TYPE | Flat |
| SKU | STK-CS89 |
| SPEED | 1100900700 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674055996 |
| VOLTAGE | 120 V |
| WEIGHT STATIC | 11 LB |
| WIDTH | 10 IN |
