| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 19.37 IN |
| CATALOG NUMBER | 9682 |
| CONNECTION DRAWING NO | 614131-106 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 1.1 A |
| FRAME | 48Y |
| FREQUENCY | 50 HZ |
| HEIGHT | 6.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 22.87 IN |
| MANUFACTURE MODEL NUMBER | 9682 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Ring/Extended Studs |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/8 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/8,1550(3),208-230,48,AIR OVER, PSC |
| PRODUCT SKU | STK-9682 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1550(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 7.5 X .5 X 8 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 7.5X.5X8 IN |
| SHAFT TYPE | Flat |
| SPEED | 1550 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230 V |
| WIDTH | 6.81 IN |
