| AMBIENT | 40°C |
| BEARING | Sleeve |
| BLOWER TYPE | Dual Wheel |
| BRAND | Century |
| C DIMENSION | 23.75 IN |
| CATALOG NUM | 9675 |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 3.3,2.3,1.7,1.2 A |
| FRAME | 42Y |
| FRAME LENGTH | 3.42 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 8.81 IN |
| HORSE POWER | 1/8-1/12-1/20-1/30 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 25.88 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 9675 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 4 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | 9675 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1550(4) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 9.8 X .5 X 9.8 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 9.8X.5X9.8 IN |
| SHAFT TYPE | Flat |
| SKU | STK-9675 |
| SPEED | 1550 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674009494 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 11 LB |
| WIDTH | 8.81 IN |
