| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | Century |
| CATALOG NUM | 9631 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 2.5/2.1 A |
| FRAME | 3.3 |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 50 HZ |
| HEIGHT | 6.38 IN |
| HORSE POWER | 1/15 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 8.39 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 9631 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | Extended Studs |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Automatic |
| PART ID | 9631 |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise Shaft End |
| RPM | 1350/1630(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.312 IN X 1.50 IN |
| SHAFT DIAMETER IN IN | 0.312 IN |
| SHAFT EXTENSION | 1.50 IN |
| SHAFT TYPE | Flat |
| SKU | STK-9631 |
| SPEED | 1350/1630 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPERSEDED PART ID | D1156 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674009067 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 4 LB |
| WIDTH | 6.38 IN |
