| BEARING | Ball |
| BLOWER TYPE | Direct Drive |
| BRAND | Century |
| C DIMENSION | 11.49 IN |
| CATALOG NUMBER | 9605A |
| CONNECTION DRAWING NO | 614131-351 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 3.9,2.2,1.6 A |
| FRAME | F48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 15.55 IN |
| MANUFACTURE MODEL NUMBER | 9605A |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Rings |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Any |
| OUTPUT | 3/4,1/2,1/3 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 3/4,1075(3),277,48,OPEN,PSC,E$ |
| PRODUCT SKU | STK-9605A |
| ROTATION | Reversible |
| RPM | 1075(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 5.50 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 5.50 IN |
| SHAFT TYPE | Flat |
| SPEED | 1075 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 277 V |
| WIDTH | 6.45 IN |
