| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 25.43 IN |
| CATALOG NUM | 953 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 0.8 - 0.5 - 0.35 A |
| FRAME | 42Y |
| FRAME LENGTH | 3.17 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 9.81 IN |
| HORSE POWER | 1/15, 1/45, 1/60 HP |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 27.88 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 953 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | 953 |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise Lead End |
| RPM | 1100(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 10.8 X .5 X 10.9 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 10.8X.5X10.9 IN |
| SHAFT TYPE | Flat |
| SKU | STK-953 |
| SPEED | 1100 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPERSEDED PART ID | 953A |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674008077 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 11 LB |
| WIDTH | 7.81 IN |
