| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 7.10 IN |
| CATALOG NUMBER | 9485 |
| DUTY | Continuous Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | .80/.50 A |
| FRAME | 4.4 |
| FREQUENCY | 60 HZ |
| HEIGHT | 8.5 IN |
| INSULATION CLASS | A |
| LEAD TIME | 17 |
| LENGTH | 4.38 IN |
| MANUFACTURE MODEL NUMBER | 9485 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Rings |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 2 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/12 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/12,1050/875,208/230,CCW,LENNOX OEM |
| PRODUCT SKU | STK-9485 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1050/875(2) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.375 IN X 0.375 X 2.50 IN |
| SHAFT DIAMETER (IN IN.) | 0.375 IN |
| SHAFT EXTENSION | 0.375X2.50 IN |
| SHAFT TYPE | Flat |
| SPEED | 1050/875 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230 V |
| WIDTH | 4.38 IN |
