| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 7.47 IN |
| CATALOG NUM | 799 |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | No |
| DUTY | Continuous Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 2.75,2.2,1.9,1.1,0.75 A |
| FRAME | 42 |
| FRAME LENGTH | 3.17 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 10.3 IN |
| HORSE POWER | 1/8, 1/10, 1/15, 1/20, 1/30 HP |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 14.88 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 799 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Lug |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 5 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | 799 |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise Shaft End |
| RPM | 1000(5) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 5.08 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 5.08 IN |
| SHAFT TYPE | Flat |
| SKU | STK-799 |
| SPEED | 1000 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPERSEDED PART ID | 799A |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674007995 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 9 LB |
| WIDTH | 12.81 IN |
