| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 11.05 IN |
| CATALOG NUMBER | 788A |
| CONNECTION DRAWING NO | 614131-242 |
| DUTY | Continuous Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 0.75 A |
| FRAME | F48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 13.78 IN |
| MANUFACTURE MODEL NUMBER | 788A |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Extended Studs |
| NOMINAL EFFICIENCY | 66 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any |
| OUTPUT | 1/4 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | .25,1075,460,48,TE,PSC,SLV BRG, |
| PRODUCT SKU | STK-788A |
| ROTATION | Reversible |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 6.06 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 6.06 IN |
| SHAFT TYPE | Double Flat |
| SPEED | 1075 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 460 V |
| WIDTH | 6.41 IN |
