| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 9.86 IN |
| CATALOG NUMBER | 752A |
| CONNECTION DRAWING NO | 614131-347 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 3.9, 2.8, 2.1, 1.6 A |
| FRAME | 48 |
| FREQUENCY | 60 HZ |
| HEIGHT | 12.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 12.87 IN |
| MANUFACTURE MODEL NUMBER | 752A |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Flexible Arms |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 4 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/4,1/6,1/8,1/10 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/4,1075(4),115,48,OPENAIR-OVER,PSC,E$ |
| PRODUCT SKU | STK-752A |
| ROTATION | Reversible |
| RPM | 1075(4) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 5.5 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 5.5 IN |
| SHAFT TYPE | Flat |
| SPEED | 1075 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 12.81 IN |
