| AMBIENT | 40°C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 10.86 IN |
| CATALOG NUM | 648A |
| CE | No |
| CONNECTION DRAWING NO | 614131-348 |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 5.6 A |
| FRAME | 48Y |
| FRAME LENGTH | 7 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 12.81 IN |
| HORSE POWER | 1/2 HP |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 12.87 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 648A |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Yoke |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any |
| OVERLOAD | Automatic |
| PART ID | 648A |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1100(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 3 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 3 IN |
| SHAFT TYPE | Flat |
| SKU | STK-648A |
| SPEED | 1100 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674010506 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 23 LB |
| WIDTH | 12.81 IN |
