| BEARING | Sleeve |
| BLOWER TYPE | Dual Wheel |
| BRAND | Century |
| C DIMENSION | 24.75 IN |
| CATALOG NUMBER | 546 |
| DUTY | Continuous Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | .78 A |
| FRAME | 42 |
| FREQUENCY | 60 HZ |
| HEIGHT | 8.81 IN |
| INSULATION CLASS | A |
| LEAD TIME | 21 |
| LENGTH | 25.88 IN |
| MANUFACTURE MODEL NUMBER | 546 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Base |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 4 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/20, 1/30, 1/50, 1/75 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/20HP,1075/4 SPD |
| PRODUCT SKU | STK-546 |
| ROTATION | Clockwise Lead End |
| RPM | 1075(4) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 10.6 X .5 X 10.6 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 10.6X.5X10.6 IN |
| SHAFT TYPE | Flat |
| SPEED | 1075 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 8.81 IN |
