| AMBIENT | 60°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 13 IN |
| CATALOG NUM | 513A |
| CE | No |
| CONNECTION DRAWING NO | 614131-015 |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 1.3,0.8,0.6 A |
| FRAME | F48Y |
| FRAME LENGTH | 3.25 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| HORSE POWER | 1/6,1/8,1/10 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 15.5 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 513A |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Lug |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | 513A |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise Lead End |
| RPM | 1040(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 7 X 0.5 X 2.14 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 7X0.5X2.14 IN |
| SHAFT TYPE | Flat |
| SKU | STK-513A |
| SPEED | 1040 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674010278 |
| VOLTAGE | 208-230 V |
| WEIGHT STATIC | 10 LB |
| WIDTH | 10.5 IN |
