| AMBIENT | 40°C |
| BEARING | Ball |
| BLOWER TYPE | Direct Drive |
| BRAND | Century |
| C DIMENSION | 11.80 IN |
| CATALOG NUM | 483A |
| CE | No |
| CONNECTION DRAWING NO | 614131-351 |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 4.9,3.3,2.2 A |
| FRAME | 48Y |
| FRAME LENGTH | 4.75 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.81 IN |
| HORSE POWER | 3/4,1/2,1/3 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 15.87 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 483A |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Rings |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Any |
| OVERLOAD | Automatic |
| PART ID | 483A |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1625(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 6 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 6 IN |
| SHAFT TYPE | Double Flat |
| SKU | STK-483A |
| SPEED | 1625 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674010216 |
| VOLTAGE | 208-230 V |
| WEIGHT STATIC | 19 LB |
| WIDTH | 6.81 IN |
