| AMBIENT | 40 °C |
| BEARING | Ball |
| BLOWER TYPE | Dual Wheel |
| BRAND | Century |
| CATALOG NUM | 452C |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous Air Over |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 0.85,0.72,0.54,0.46 A |
| FRAME | 42 |
| FRAME LENGTH | 3.58 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.44 IN |
| HORSE POWER | 1/20,1/25,1/35,1/50 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 22.88 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 452C |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | PSC |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 4 |
| OVERLOAD | Automatic |
| PART ID | 452C |
| ROTATION | Clockwise Lead End |
| RPM | 1075(4) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 10.33 X .5 X 10.33 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 9.72 X .5 X 8.72 IN |
| SHAFT TYPE | Flat |
| SPEED | 1075 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674077332 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 11.13 LB |
| WIDTH | 6.25 IN |
