| AMBIENT | 40°C |
| BEARING | Ball |
| BLOWER TYPE | Furnace |
| BRAND | Century |
| C DIMENSION | 6.83 IN |
| CATALOG NUM | 415 |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 2.5 A |
| FRAME | 42 |
| FRAME LENGTH | 2.92 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.81 IN |
| HORSE POWER | 1/12 HP |
| INSULATION CLASS | A |
| LEAD TIME | 17 |
| LENGTH | 8.81 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 415 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | Extended Studs |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | 415 |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise Shaft End |
| RPM | 1050(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.375 IN X 3.33 IN |
| SHAFT DIAMETER IN IN | 0.375 IN |
| SHAFT EXTENSION | 3.33 IN |
| SHAFT TYPE | Flat |
| SKU | STK-415 |
| SPEED | 1050 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674006974 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 8 LB |
| WIDTH | 6.88 IN |
