| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | Century |
| CATALOG NUM | 349 |
| CE | No |
| CSA | No |
| DUTY | Continuous Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | .46 A |
| FRAME | 3.3 |
| FRAME LENGTH | 4.74 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.38 IN |
| HORSE POWER | 1/125 HP |
| INSULATION CLASS | A |
| LEAD TIME | 18 |
| LENGTH | 10.21 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 349 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | Extended Studs |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Impedance |
| PART ID | 349 |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise Shaft End |
| RPM | 3000(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.250 IN X 2.50 IN |
| SHAFT DIAMETER IN IN | 0.250 IN |
| SHAFT EXTENSION | 2.50 IN |
| SHAFT TYPE | Flat |
| SKU | STK-349 |
| SPEED | 3000 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPERSEDED PART ID | D408 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674006622 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 3 LB |
| WIDTH | 6.5 IN |
