| AMBIENT | 40°C |
| BEARING | Unit |
| BRAND | Century |
| CATALOG NUM | 291 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 1.7 A |
| FRAME | UNIT BEARING |
| FRAME LENGTH | 4.91 IN |
| FRAME MATERIAL | Cast Iron |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.87 IN |
| HORSE POWER | 50 W |
| INSULATION CLASS | A |
| LEAD TIME | 18 |
| LENGTH | 10.9 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 291 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | 2 BOSS/OSE 3 HOLES |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Automatic |
| PART ID | 291 |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise Lead End |
| RPM | 1500(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.312 IN X 2.98 IN |
| SHAFT DIAMETER IN IN | 0.312 IN |
| SHAFT EXTENSION | 2.98 IN |
| SHAFT TYPE | Flat |
| SKU | STK-291 |
| SPEED | 1500 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674006370 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 8 LB |
| WIDTH | 6.87 IN |
