| AMBIENT | 40°C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 21 IN |
| CATALOG NUM | 427 |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 0.48/0.38 A |
| FRAME | 42 |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 8.63 IN |
| HORSE POWER | 1/20, 1/30 HP |
| INSULATION CLASS | A |
| LEAD TIME | 32 |
| LENGTH | 22.63 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | 427 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 2 |
| ORIENTATION | Any |
| OVERLOAD | Automatic |
| PART ID | 427 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1320/1050(2) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 8.37 X .5 X 8.38 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 8.37X.5X8.38 IN |
| SHAFT TYPE | Flat |
| SKU | STK-0427 |
| SPEED | 1320/1050 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674007018 |
| VOLTAGE | 277 V |
| WEIGHT STATIC | 13 LB |
| WIDTH | 9.63 IN |
