| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | US Motors® |
| C DIMENSION | 16.8 IN |
| CATALOG NUM | WD5P2DCR |
| CE | Yes |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | TOTALLY ENCLOSED FAN COOLED |
| FL AMPS | 13.5 to 12.5/6.2 A |
| FRAME | 184TC |
| FRAME MATERIAL | Stainless Steel |
| FRAME STATIC | 184 TC |
| FREQUENCY | 50/60 HZ |
| HORSE POWER | 5 HP |
| INSULATION CLASS | F |
| KVA CODE | J |
| LEAD TIME | 1 |
| MFG MODEL NUM | WD5P2DCR |
| MIN QUANTITY INCREMENT | 1 |
| MOUNTING | Rigid Base |
| NOMINAL EFFICIENCY | 89.5 |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| PART ID | WD5P2DCR |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1755(1) |
| RPM STATIC | 1800 |
| SERVICE FACTOR | 1.15 |
| SHAFT | 1.125 IN X 2.75 IN |
| SHAFT DIAMETER IN IN | 1.125 IN |
| SHAFT EXTENSION | 2.75 IN |
| SHAFT TYPE | Keyed |
| SPEED | 1755 |
| SUPPLIER | Nidec Motor Corporation |
| SUPPLIER ACCOUNT NUMBER | 00059552 |
| UOM | Each |
| VOLTAGE | 460/208-230 V |
| VOLTAGE STATIC | 208-230/460 |
| WEIGHT STATIC | 87 LB |
