| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | US Motors® |
| C DIMENSION | 13.3 IN |
| CATALOG NUM | WD34C2JC |
| CATALOG NUM STATIC | Wd34C2Jc |
| COUNTRY OF ORIGIN | Mexico |
| DUTY | Continuous |
| ENCLOSURE | TOTALLY ENCLOSED FAN COOLED |
| FL AMPS | 12.8/6.4-6.5 A |
| FRAME | 56C |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | 56C |
| FREQUENCY | 60 HZ |
| HORSE POWER | 3/4 HP |
| HORSE POWER STATIC | 4-Mar |
| INSULATION CLASS | F |
| KVA CODE | L |
| LEAD TIME | 17 |
| MANUFACTURER | Nidec Motor Corporation |
| MFG MODEL NUM | WD34C2JC |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | C-Face/Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| PART ID | WD34C2JC |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1725(1) |
| RPM STATIC | 1800 |
| SERVICE FACTOR | 1.15 |
| SHAFT DIAMETER IN IN | 0.625 |
| SKU | NM-WD34C2JC |
| SPEED | 1725 |
| SUPPLIER | Nidec Motor Corporation |
| UOM | Each |
| UPC NUMBER | 786382071370 |
| VOLTAGE | 115/208-230 V |
| VOLTAGE STATIC | 115/202-230 |
| WEIGHT STATIC | 32.0 LB |
