| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | US Motors® |
| C DIMENSION | 21.4 IN |
| CATALOG NUM | WD10P1DC |
| COUNTRY OF ORIGIN | Mexico |
| DUTY | Continuous |
| ENCLOSURE | TOTALLY ENCLOSED FAN COOLED |
| FL AMPS | 23/11.5 A |
| FRAME | 215TC |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 10 HP |
| INSULATION CLASS | F |
| KVA CODE | G |
| LEAD TIME | 21 |
| MANUFACTURER | Nidec Motor Corporation |
| MFG MODEL NUM | WD10P1DC |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3Ph |
| MOUNTING | Horizontal/Foot |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| PART ID | WD10P1DC |
| PRODUCT GROUP | 3050 |
| ROTATION | Dual |
| RPM | 3529(1) |
| SERVICE FACTOR | 1.15 |
| SKU | NM-WD10P1DC |
| SPEED | 3529 |
| SUPPLIER | Nidec Motor Corporation |
| UOM | Each |
| UPC NUMBER | 786382106560 |
| VOLTAGE | 230/460 V |
| WEIGHT STATIC | 145 LB |
