| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | US Motors |
| C DIMENSION | 12.5 IN |
| CATALOG NUM | FD34CM2PZYR |
| CATALOG NUM STATIC | Fd34Cm2Pzyr |
| COUNTRY OF ORIGIN | Mexico |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | Totally Enclosed Fan Cooled |
| FRAME | 56YZ |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | 56N |
| FREQUENCY | 50/60 HZ |
| HORSE POWER | 3/4 HP |
| HORSE POWER STATIC | 4-Mar |
| INSULATION CLASS | F |
| LEAD TIME | #REF! |
| MANUFACTURER | Nidec Motor Corporation |
| MFG MODEL NUM | FD34CM2PZYR |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | CAPACITOR START |
| MOUNTING | Footless |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Manual |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM STATIC | 1800 |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SKU | NM-FD34CM2PZYR |
| SPEED | 1725 |
| SUPPLIER | Nidec Motor Corporation |
| UOM | Each |
| UPC NUMBER | 786382025915 |
| VOLTAGE | 115/230 V |
| VOLTAGE STATIC | 230/115 |
| WEIGHT STATIC | 32 LB |
