| AMBIENT | 50 °C |
| BLOWER TYPE | #N/A |
| BRAND | US Motors |
| C DIMENSION | 10.3 IN |
| CATALOG NUM | FD34CA1PZ |
| COUNTRY OF ORIGIN | Mexico |
| DUTY | Continuous |
| ENCLOSURE | Totally Enclosed Air Over |
| FRAME | 56Z |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 3/4 HP |
| INSULATION CLASS | B |
| LEAD TIME | #REF! |
| MANUFACTURER | Nidec Motor Corporation |
| MFG MODEL NUM | FD34CA1PZ |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | CAPACITOR START |
| MOUNTING | Rigid Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Manual |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise |
| RPM | 3600 |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SKU | NM-FD34CA1PZ |
| SPEED | 3450 |
| SUPPLIER | Nidec Motor Corporation |
| UOM | Each |
| UPC NUMBER | 786382025878 |
| VOLTAGE | 115/230 V |
| WEIGHT STATIC | 22.44 LB |
