| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | US Motors |
| C DIMENSION | 12.7 IN |
| CATALOG NUM | FD1CM2P14 |
| COUNTRY OF ORIGIN | Mexico |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | Totally Enclosed Fan Cooled |
| FRAME | 143T |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1 HP |
| INSULATION CLASS | F |
| LEAD TIME | #REF! |
| MANUFACTURER | Nidec Motor Corporation |
| MFG MODEL NUM | FD1CM2P14 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | CAPACITOR START |
| MOUNTING | Rigid Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Manual |
| POWER RATING IN KW | 0.75 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1800 |
| SERVICE FACTOR | 1.15 |
| SKU | NM-FD1CM2P14 |
| SPEED | 1725 |
| SUPPLIER | Nidec Motor Corporation |
| UOM | Each |
| UPC NUMBER | 786382078881 |
| VOLTAGE | 115/230 V |
| WEIGHT STATIC | 38.7 LB |
