| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | US Motors |
| C DIMENSION | 13.8 IN |
| CATALOG NUM | FD1AA4KCR |
| CE | Y |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Y |
| DUTY | Continuous |
| ENCLOSURE | Totally Enclosed Air Over |
| FRAME | 56YZ |
| FRAME MATERIAL | Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1 HP |
| INSULATION CLASS | B |
| LEAD TIME | #REF! |
| MANUFACTURER | Nidec Motor Corporation |
| MFG MODEL NUM | FD1AA4KCR |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | PERMANENT SPLIT CAPACITOR |
| MOUNTING | Round |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 8 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| POWER RATING IN KW | 0.75 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise |
| RPM | 900 |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SKU | NM-FD1AA4KCR |
| SPEED | 850 |
| SUPPLIER | Nidec Motor Corporation |
| UOM | Each |
| UPC NUMBER | 786382058487 |
| VOLTAGE | 230 V |
| WEIGHT STATIC | 38 LB |
