| AMBIENT | 40 °C |
| BEARING | Ball |
| BLOWER TYPE | #N/A |
| BRAND | US Motors |
| C DIMENSION | 11.25 IN |
| CATALOG NUM | FD13SM2DZYR |
| DUTY | Continuous |
| ENCLOSURE | Totally Enclosed Fan Cooled |
| FRAME | 56Y |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 50/60 HZ |
| HORSE POWER | 1/3 HP |
| INSULATION CLASS | F |
| LEAD TIME | #REF! |
| MANUFACTURER | Nidec Motor Corporation |
| MFG MODEL NUM | FD13SM2DZYR |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3PHASE |
| MOUNTING | Footed |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM STATIC | 1800 |
| SERVICE FACTOR | 1 |
| SKU | NM-FD13SM2DZYR |
| SPEED | 1725 |
| SUPPLIER | Nidec Motor Corporation |
| UOM | Each |
| VOLTAGE | 208-230/460 V |
| WEIGHT STATIC | 42.5 LB |
