| AMBIENT | 40 °C |
| BLOWER TYPE | #N/A |
| BRAND | US Motors |
| C DIMENSION | 10.8 IN |
| CATALOG NUM | FD12SA2D |
| COUNTRY OF ORIGIN | Mexico |
| DUTY | Continuous |
| ENCLOSURE | Totally Enclosed Air Over |
| FRAME | 56H |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/2 HP |
| INSULATION CLASS | F |
| LEAD TIME | #REF! |
| MANUFACTURER | Nidec Motor Corporation |
| MFG MODEL NUM | FD12SA2D |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3PHASE |
| MOUNTING | Rigid Base |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1800 |
| SERVICE FACTOR | 1.15 |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SKU | NM-FD12SA2D |
| SPEED | 1725 |
| SUPPLIER | Nidec Motor Corporation |
| UOM | Each |
| UPC NUMBER | 786382088453 |
| VOLTAGE | 208-230/460 V |
| WEIGHT STATIC | 16.7 LB |
