| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | US Motors |
| C DIMENSION | 11.69 IN |
| CATALOG NUM | FD12AA4P |
| COUNTRY OF ORIGIN | Mexico |
| DUTY | Continuous |
| ENCLOSURE | Totally Enclosed Air Over |
| FRAME | 56Z |
| FRAME MATERIAL | Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/2 HP |
| INSULATION CLASS | B |
| LEAD TIME | #REF! |
| MANUFACTURER | Nidec Motor Corporation |
| MFG MODEL NUM | FD12AA4P |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | PERMANENT SPLIT CAPACITOR |
| MOUNTING | Rigid Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 8 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 900 |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SKU | NM-FD12AA4P |
| SPEED | 825 |
| SUPPLIER | Nidec Motor Corporation |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786382058524 |
| VOLTAGE | 115/230 V |
| WEIGHT STATIC | 35 LB |
