| AMBIENT | 40 °C |
| BRAND | US Motors® |
| C DIMENSION | 16.1 IN |
| CATALOG NUM | C5P2B |
| COUNTRY OF ORIGIN | Mexico |
| DUTY | Continuous |
| ENCLOSURE | TOTALLY ENCLOSED |
| FL AMPS | 12.5/6.3 A |
| FRAME | 184T |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 5 HP |
| INSULATION CLASS | F |
| KVA CODE | J |
| LEAD TIME | 17 |
| MANUFACTURER | Nidec Motor Corporation |
| MFG MODEL NUM | C5P2B |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3Ph |
| MOUNTING | Horizontal/Foot |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| PART ID | C5P2B |
| PRODUCT GROUP | 3050 |
| RPM | 1755(1) |
| SERVICE FACTOR | 1.15 |
| SHAFT DIAMETER IN IN | 1.125 |
| SKU | NM-C5P2B |
| SPEED | 1755 |
| SUPPLIER | Nidec Motor Corporation |
| UOM | Each |
| VOLTAGE | 230/460 V |
| WEIGHT STATIC | 120 LB |
