| BEARING | Ball |
| BRAND | US Motors |
| CATALOG NUMBER | AGD15FL1 |
| CURRENT2 | 7.7/15.4 A |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| INSULATION CLASS | F |
| KVA CODE | G |
| LEAD TIME | 17 |
| MANUFACTURE MODEL NUMBER | AGD15FL1 |
| MANUFACTURER | Nidec Motor Corporation |
| MOTOR TYPE | FHP |
| MOUNTING | Thru Bolt/Base |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 1-1/2 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1.5,3600,115/230,48Y,ODP,CAP |
| PRODUCT SKU | NM-AGD15FL1 |
| ROTATION | Counterclockwise Drive End |
| RPM | 3450(1) |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER (IN IN.) | 0.375 IN |
| SHAFT TYPE | Threaded |
| SUPPLIER | Nidec Motor Corporation |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115/230 V |
| WEIGHT | 25 LB |
