| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | US Motors® |
| C DIMENSION | 7.6 IN |
| CATALOG NUM | 3252 |
| CE | Yes |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | TOTALLY ENCLOSED |
| FL AMPS | 3.1 A |
| FRAME | 48N |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/6 HP |
| INSULATION CLASS | B |
| KVA CODE | R |
| LEAD TIME | 1 |
| MFG MODEL NUM | 3252 |
| MIN QUANTITY INCREMENT | 1 |
| MOUNTING | Flange |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Manual |
| PART ID | 3252 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1725(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 1.5 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 1.5 IN |
| SKU | NM-3252 |
| SPEED | 1725 |
| STARTING TYPE | Capacitor |
| SUPPLIER | Nidec Motor Corporation |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786382002961 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 14 LB |
