| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| CATALOG NUMBER | P244 |
| CONNECTION DRAWING NO | 154A2455 |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 6.3-5.0/2.5 A |
| FRAME | 56Z |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.5 IN |
| INSULATION CLASS | B |
| KVA CODE | C |
| LEAD TIME | 17 |
| LENGTH | 15.63 IN |
| MANUFACTURE MODEL NUMBER | P244 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MOTOR TYPE | Psc |
| MOUNTING | Rigid Base |
| NOMINAL EFFICIENCY | 69 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal/Vertical |
| OUTPUT | 1 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1,1200,208-230/460,56,ODP,PSC |
| PRODUCT SKU | MTG-P244 |
| ROTATION | Counterclockwise/Clockwise |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.63 IN X 6 IN |
| SHAFT DIAMETER (IN IN.) | 0.63 IN |
| SHAFT EXTENSION | 6 IN |
| SPEED | 1075 |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230/460 V |
| WIDTH | 9.88 IN |
